Concrete is prepared from constituent materials like cement, water, fine aggregate, coarse aggregate and other enhancing materials that improve specific aspects of the concrete. The quantity of cement and water is mainly responsible for the properties of the concrete being prepared like strength, workability, durability, heat or radiation resistance of an individual type of concrete.
A concrete mix is generally prepared by following two mixing procedures, Nominal Mix and Design Mix, which involves mixing of appropriate proportions of constituent materials to achieve the desired quality. The nominal mix is prepared for minor construction processes such as small houses. The typical mix proportion used for preparing a nominal mix is 1:2:4(cement:sand:aggregate) based on either weight or volume of the materials.
PCC in Construction
Plain Cement Concrete, also known as Normal Cement Concrete is a mixture whose constituents are cement, fine aggregate(sand), coarse aggregate and water only. There is no type of reinforcement embedded inside or mixed with the concrete due to which it cannot be used for the construction of columns, beams, slab, etc that have to bear tensile load.
This type of concrete is only capable of withstanding compressive loads and because of this it can be used for the construction of floors, retaining walls, roads, etc. It has quite low toughness index, flexural rigidity, yielding strength, etc.
Components of PCC
- Cement: Acts as the binding agent.
- Fine Aggregate (Sand): Enhances the workability and compactness.
- Coarse Aggregate: Provides strength and durability.
- Water: Facilitates the chemical reaction for hydration and setting.
Applications of PCC
PCC is primarily used for:
- Flooring in buildings and industrial structures
- Leveling courses for foundations
- Road pavement layers
- Retaining walls and boundary walls
- DPC (Damp Proof Course) layers in buildings
Advantages of PCC
- Provides a smooth and uniform surface
- Reduces capillary action of moisture
- Increases the durability of the structure
- Acts as a firm base for reinforced structures
IS Codes for PCC
- IS 456:2000 – Code of Practice for Plain and Reinforced Concrete
- IS 383:2016 – Specifications for Fine and Coarse Aggregates
- IS 10262:2019 – Guidelines for Concrete Mix Design
- IS 456:2000 – General specifications for concrete structures
Download our IS code App for all kinds of Is codes in Civil engineering.
RCC in Construction
Reinforced Cement Concrete (RCC) is PCC integrated with steel reinforcement bars (rebars) to enhance tensile strength. Since concrete is weak in tension but strong in compression, reinforcement helps it bear both compressive and tensile loads effectively.
RCC is suitable for the construction of bothe tensile as well as compression elements such as columns, beams, slabs, etc, and has high toughness index, flexural rigidity and yielding strength. Due to the introduction of steel reinforcements the depth of the concrete section can be reduced, thereby reducing overall cost.
Components of RCC
- Cement: Provides strength and binds other materials together.
- Fine Aggregate (Sand): Improves compactness and workability.
- Coarse Aggregate: Adds bulk and strength.
- Water: Essential for hydration and setting.
- Steel Reinforcement: Increases tensile strength and durability.
Applications of RCC
RCC is extensively used in:
- Beams and columns
- Slabs and roofs
- Foundations and footings
- Bridges, tunnels, and dams
- High-rise buildings and infrastructure projects
Advantages of RCC
- Higher flexural and tensile strength
- Increased load-bearing capacity
- Improved durability and fire resistance
- Reduced section depth, lowering material costs
- Long-lasting performance with minimal maintenance
IS Codes for RCC
- IS 456:2000 – Code of Practice for Plain and Reinforced Concrete
- IS 1786:2008 – Specifications for High Strength Deformed Steel Bars
- IS 13920:2016 – Ductile Detailing of Reinforced Concrete Structures
- IS 3370:2009 – Code of Practice for Concrete Structures for Water Retention
DPC in Construction
Damp Proof Course (DPC) is a protective layer of concrete, bitumen, or polymer-based materials provided below the plinth level to prevent moisture ingress into the walls and floors. It acts as a barrier against the capillary rise of water from the ground.
Components of DPC
- Cement: Forms the base binding material.
- Fine Aggregate (Sand): Provides consistency and uniformity.
- Coarse Aggregate: Enhances durability and strength.
- Water: Facilitates the hydration process.
- Waterproofing Materials: Bitumen, polymers, or special additives improve resistance against moisture.
Applications of DPC
- Residential and commercial buildings
- Retaining walls and basements
- Water tanks and underground structures
Advantages of DPC
- Prevents structural damage due to moisture
- Enhances the durability of the building
- Reduces the risk of mold and fungus formation
- Protects plaster and paint from peeling
Damp Proof Course is similar to PCC which is provided below the plinth level of a building or structure to prevent movement of moisture or dampness through the walls and floors. The depth of DPC provided for buildings is about 50mm and is kept at about 1 ft from the ground value or as specified in the design of structure.
DPC does not serve any purpose of bearing loads of any kind, it is only provided to protect the wall and floor from penetration of moisture. DPC can also prevent the movement of water into the superstructure from the ground due to the capillary action of water.
IS Codes for DPC
- IS 3067:1988 – Code of Practice for Installation of Damp-Proofing Treatment
- IS 456:2000 – General specifications for concrete structures
- IS 1200- Part 3:1976 – Methods of Measurement of DPC
Importance of Concrete in Modern Construction
Concrete is one of the most versatile and widely used materials in the construction industry due to its affordability, strength, and adaptability. Some key aspects that highlight its significance include:
- Durability: Concrete structures have a long lifespan with minimal maintenance.
- Versatility: Concrete can be molded into any shape and used in diverse applications.
- Cost-Effectiveness: Compared to other materials, concrete is economical and widely available.
- Fire Resistance: Concrete exhibits excellent resistance to fire and extreme temperatures.
- Sustainability: Modern concrete technology integrates recycled materials, reducing environmental impact.
Conclusion
Concrete remains a fundamental component of modern construction, with various types and mix designs catering to different structural requirements. Understanding the differences between PCC, RCC, and DPC, along with adherence to IS codes, ensures the safe and efficient application of concrete in infrastructure projects. By following proper mix proportions, design guidelines, and reinforcement techniques, construction professionals can optimize performance, durability, and sustainability in their projects.
FAQs
Q1: What is the difference between PCC and RCC?
A1: PCC is plain concrete without reinforcement, used for flooring, leveling, and foundations. RCC includes steel reinforcement, making it suitable for beams, columns, and slabs that bear both tensile and compressive loads.
Q2: Why is DPC necessary in buildings?
A2: DPC prevents moisture from rising into the structure, protecting walls and floors from dampness, mold, and structural damage.
Q3: What is the standard mix ratio for nominal concrete?
A3: The commonly used nominal mix ratio is 1:2:4 (cement:sand:aggregate), but this can vary based on specific requirements and IS codes.
Q4: Which IS code is used for RCC design?
A4: IS 456:2000 provides the guidelines for designing and constructing RCC structures.
